House Plan: DFD-5840

See All 8 Photos > (photographs may reflect modified homes)
© copyright by designer
SQ FT
1,514
BEDS
3
BATHS
2
STORIES
1
CARS
2
HOUSE PLANS SALE
START AT  $935.00
For questions and help, live chat, email or call us at 877-895-5299
Floor Plans
Click to Zoom In on Floor Plan

About House Plan 5840:
The craftsman detailing add charm to this narrow plan. The front porch projecting beyond the garage wall helps minimize the impact of a front entry. Upon entering the house, ceilings soar to 14' high carrying the vault through the entire house. The fireplace wall acts to separate the dining/kitchen from the living area. A command center for the home's computer is nestled in the hall outside the children's bedrooms.
House Plan Pricing
STEP 1 Select Your Package

PDF Bid Set


Home plans stamped "NOT FOR CONSTRUCTION" for cost estimating and bidding purposes only; a minimum 5 set plan package must be purchased within 90 days for a license to build plan set; a credit will be applied towards your house plan upgrade

PDF Bid Set $725
Immediate Delivery!
Digital set of plans for bidding purposes only

PDF Single Build


Digital plans emailed to you in PDF format that allows for printing copies and sharing electronically with contractors, subs, decorators, and more. This package includes a license to build the home one time.

PDF Single Build $1,100
Immediate Delivery!
Most recommended package

5 Printed Sets


Five Printed Sets of Residential Construction Drawings are typically 24” x 36” documents and come with a license to construct a single residence shipped to a physical address. Keep in mind PDF Plan Packages are our most popular choice which allows you to print as many copies as you need and to electronically send files to your builder, subcontractors, etc.

5 Printed Sets $1,200
Five printed sets of house plans
STEP 2 CHOOSE YOUR FOUNDATION
STEP 3 OPTIONAL ADD-ONS
Subtotal
$1100
FREE SHIPPING

Plan Details
See All Details
Finished Square Footage
1,514 Sq. Ft.
Main Level:
1,514 Sq. Ft.
Lower Level:
1,514 Sq. Ft.
Total:
Room Details
3
Bedrooms:
2
Full Baths:
General House Information
1
Number of Stories:
37' 0"
Width:
61' 0"
Depth:
Single
Dwelling Number:
None
Bonus Access:
Unfinished Square Footage
420 Sq. Ft.
Garage:
85 Sq. Ft.
Porch:
110 Sq. Ft.
Patio:
GARAGE
Front
Garage Location:
2
Garage Size:
Exterior Style
Bungalow
Cottage
Craftsman
Collections
Affordable
Empty Nester
First Home
Old House Classics
Open Floor Plan
PDFs Fast!
Split Bedroom
Foundation
WALK OUT BASEMENT
Framing Information
Truss
Roof Framing:
2x4
Exterior Wall Framing:
Roof Pitch
7/12
Primary:
Roof Load
20
Live:
10
Dead:
Insulation (R)
Per IRC Climate Zones
House And Ceiling Heights
8
First Floor Ceiling:
25' 0"
Maximum House Height:
Key Features
Attached
Basement
Covered Front Porch
Covered Rear Porch
Deck
Dining Room
Double Vanity Sink
Front Porch
Front-entry
Great Room
Laundry 1st Fl
Primary Bdrm Main Floor
Nook / Breakfast Area
Open Floor Plan
Peninsula / Eating Bar
Rear Porch
Screened Porch/Sunroom
Separate Tub and Shower
Slab
Split Bedrooms
Storage Space
Suited for narrow lot
Suited for sloping lot
Unfinished Space
Vaulted Ceilings
Walk-in Closet
Walkout Basement
