House Plan: DFD-5846

Pin It
See All 5 Photos > (photographs may reflect modified homes)
© copyright by designer
SQ FT
1,667
BEDS
3
BATHS
2
STORIES
1
CARS
2
HOUSE PLANS SALE
START AT  $880.00
For questions and help, live chat, email or call us at 877-895-5299
Floor Plan
Lower Level
Floor Plans
Click to Zoom In on Floor Plan

About House Plan 5846:
Bay windows add light to this small drive under garage ranch plan and help maximize space. Dining, breakfast and master all take advantage of that little bit of extra space making each space more comfortable to furnish. A washer/dryer closet in the hall keeps one from climbing stairs with loads of laundry.
House Plan Pricing
STEP 1 Select Your Package

PDF Bid Set

Home plans stamped "NOT FOR CONSTRUCTION" for cost estimating and bidding purposes only; a minimum 5 set plan package must be purchased within 90 days for a license to build plan set; a credit will be applied towards your house plan upgrade

PDF Bid Set $725
Immediate Delivery!
Digital set of plans for bidding purposes only

PDF Single Build

Digital plans emailed to you in PDF format that allows for printing copies and sharing electronically with contractors, subs, decorators, and more. This package includes a license to build the home one time.

PDF Single Build $1,100
Immediate Delivery!
Most recommended package

5 Printed Sets

Five Printed Sets of Residential Construction Drawings are typically 24” x 36” documents and come with a license to construct a single residence shipped to a physical address. Keep in mind PDF Plan Packages are our most popular choice which allows you to print as many copies as you need and to electronically send files to your builder, subcontractors, etc.

5 Printed Sets $1,200
Five printed sets of house plans
STEP 2 CHOOSE YOUR FOUNDATION
STEP 3 OPTIONAL ADD-ONS
Subtotal
$1100
FREE SHIPPING

Detailed Plan Packages & Pricing
Our Structural Detail & IRC Guarantee
Architect's Preferred Home Products
Plan Details
See All Details
Finished Square Footage
1,667 Sq. Ft.
Main Level:
800 Sq. Ft.
Lower Level:
1,667 Sq. Ft.
Total:
Room Details
3
Bedrooms:
2
Full Baths:
General House Information
1
Number of Stories:
54' 0"
Width:
30' 0"
Depth:
Single
Dwelling Number:
Unfinished Square Footage
835 Sq. Ft.
Garage:
224 Sq. Ft.
Porch:
168 Sq. Ft.
Deck:
GARAGE
Under
Garage Location:
2
Garage Size:
Exterior Style
Country
Farmhouse
Ranch
Collections
Affordable
First Home
Old House Classics
PDFs Fast!
Foundation
WALK OUT BASEMENT
Framing Information
Stick
Roof Framing:
2x4
Exterior Wall Framing:
Roof Pitch
6/12
Primary:
Roof Load
20
Live:
10
Dead:
Insulation (R)
Per IRC Climate Zones
House And Ceiling Heights
8
First Floor Ceiling:
18' 0"
Maximum House Height:
Key Features
Attached
Basement
Covered Front Porch
Deck
Dining Room
Double Vanity Sink
Drive-under
Fireplace
Foyer
Front Porch
His and Hers Primary Closets
Laundry 1st Fl
Nook / Breakfast Area
Suited for sloping lot
Vaulted Ceilings
Walk-in Closet
Walk-in Pantry
Walkout Basement
