House Plan: DFD-1059

See All 2 Photos > (photographs may reflect modified homes)
© copyright by designer
SQ FT
1,364
BEDS
3
BATHS
2
STORIES
1
CARS
2
HOUSE PLANS SALE
START AT  $807.50
For questions and help, live chat, email or call us at 877-895-5299
Floor Plans
Click to Zoom In on Floor Plan

About House Plan 1059:
Here's the ideal home to nestle in the woods of a mountain community. Board and batten siding and braced porch columns create a warm rustic feel to this raised ranch plan. It offers an ideal design for a vacation home or the first time home buyer.

The open plan features a central fireplace separating the living area from the dining room. Both enjoy volume ceilings and lots of windows to capture the view of a perfect mountain retreat.

No space is lost to hall with this split bedroom design. Although the master opens off the front entry it enjoys privacy created by the stair wall that separates the living area from the bedroom. A large window wall provides views and plenty of light.
House Plan Pricing
STEP 1 Select Your Package

PDF Bid Set


Home plans stamped "NOT FOR CONSTRUCTION" for cost estimating and bidding purposes only; a minimum 5 set plan package must be purchased within 90 days for a license to build plan set; a credit will be applied towards your house plan upgrade

PDF Bid Set $600
Immediate Delivery!
Digital set of plans for bidding purposes only

PDF Single Build


Digital plans emailed to you in PDF format that allows for printing copies and sharing electronically with contractors, subs, decorators, and more. This package includes a license to build the home one time.

PDF Single Build $950
Immediate Delivery!
Most recommended package

5 Printed Sets


Five Printed Sets of Residential Construction Drawings are typically 24” x 36” documents and come with a license to construct a single residence shipped to a physical address. Keep in mind PDF Plan Packages are our most popular choice which allows you to print as many copies as you need and to electronically send files to your builder, subcontractors, etc.

5 Printed Sets $1,000
Five printed sets of house plans
STEP 2 CHOOSE YOUR FOUNDATION
STEP 3 OPTIONAL ADD-ONS
Subtotal
$950
FREE SHIPPING

Plan Details
See All Details
Finished Square Footage
1,364 Sq. Ft.
Main Level:
1,364 Sq. Ft.
Total:
Room Details
3
Bedrooms:
2
Full Baths:
General House Information
1
Number of Stories:
52' 0"
Width:
33' 6"
Depth:
Single
Dwelling Number:
Unfinished Square Footage
780 Sq. Ft.
Garage:
120 Sq. Ft.
Porch:
140 Sq. Ft.
Deck:
520 Sq. Ft.
Bonus Room:
GARAGE
Under
Garage Location:
2
Garage Size:
Exterior Style
Country
Farmhouse
Southern
Collections
First Home
Mountain
PDFs Fast!
Split Bedroom
Vacation
Foundation
Basement Alternate
WALK OUT BASEMENT
Framing Information
Stick
Roof Framing:
2x4
Exterior Wall Framing:
Roof Pitch
6/12
Primary:
Roof Load
20
Live:
10
Dead:
Insulation (R)
Per IRC Climate Zones
House And Ceiling Heights
8
First Floor Ceiling:
17' 0"
Maximum House Height:
Key Features
Basement
Covered Front Porch
Deck
Dining Room
Drive-under
Fireplace
Front Porch
Great Room
Laundry 1st Fl
Primary Bdrm Main Floor
Open Floor Plan
Side-entry
Split Bedrooms
Suited for corner lot
Suited for narrow lot
Suited for sloping lot
Unfinished Space
Vaulted Ceilings
Walkout Basement
Workshop
