House Plan: DFD-3864

See All 4 Photos > (photographs may reflect modified homes)
© copyright by designer
SQ FT
1,655
BEDS
3
BATHS
2
STORIES
1
CARS
2
HOUSE PLANS SALE
START AT  $752.00
For questions and help, live chat, email or call us at 877-895-5299
Floor Plans
Click to Zoom In on Floor Plan

About House Plan 3864:
This home's striking entrance features a shed dormer topping a trellis covering the double doors flanked by stonework. Inside, the columned living and dining rooms share a dramatic sloped ceiling. The living room enjoys a fireplace and sliding glass doors leading to the backyard terrace. The generous kitchen overlooks the family room which also faces out to the rear yard. The master bedroom boasts multiple closets and a private bath with a dual-sink vanity and a whirlpool tub.
House Plan Pricing
STEP 1 Select Your Package

PDF Bid Set


Home plans stamped "NOT FOR CONSTRUCTION" for cost estimating and bidding purposes only; a minimum 5 set plan package must be purchased within 90 days for a license to build plan set; a credit will be applied towards your house plan upgrade

PDF Bid Set $710
Immediate Delivery!
Digital set of plans for bidding purposes only

PDF Single Build


Digital plans emailed to you in PDF format that allows for printing copies and sharing electronically with contractors, subs, decorators, and more. This package includes a license to build the home one time.

PDF Single Build $940
Immediate Delivery!
Most recommended package

5 Printed Sets


Five Printed Sets of Residential Construction Drawings are typically 24” x 36” documents and come with a license to construct a single residence shipped to a physical address. Keep in mind PDF Plan Packages are our most popular choice which allows you to print as many copies as you need and to electronically send files to your builder, subcontractors, etc.

5 Printed Sets $1,050
Five printed sets of house plans

8 Printed Sets


Eight Printed Sets of Construction Drawings, typically 24” x 36” documents, with a license to construct a single residence shipped to your physical address. PDF Plan Packages are our most popular choice which allows you to print as many copies as you need and to electronically send files to your builder, subcontractors, bank/mortgage reps, material stores, decorators and more.

8 Printed Sets $1,125
Eight printed sets of house plans
STEP 2 CHOOSE YOUR FOUNDATION
STEP 3 OPTIONAL ADD-ONS
Subtotal
$940
FREE SHIPPING

Plan Details
See All Details
Finished Square Footage
1,655 Sq. Ft.
Main Level:
1,655 Sq. Ft.
Total:
Room Details
3
Bedrooms:
2
Full Baths:
General House Information
1
Number of Stories:
62' 4"
Width:
55' 4"
Depth:
Single
Dwelling Number:
Unfinished Square Footage
448 Sq. Ft.
Garage:
GARAGE
Front
Garage Location:
2
Garage Size:
Exterior Style
Beach
Contemporary
Modern
Ranch
Collections
Old House Classics
Open Floor Plan
Vacation
Foundation
Basement
Crawl Space
Slab Foundation
Framing Information
Stick
Roof Framing:
2x6
Exterior Wall Framing:
Roof Pitch
5/12
Primary:
Roof Load
30
Live:
7
Dead:
Insulation (R)
19
Exterior Wall:
0
Interior Wall:
38
Ceiling:
19
Floor:
House And Ceiling Heights
8'-1"
First Floor Ceiling:
22' 0"
Maximum House Height:
Facade
Owner's Choice
OwnersChoice
Key Features
Attached
Basement
Crawlspace
Dining Room
Family Kitchen
Fireplace
Formal Dining Room
Formal LR
Front Porch
Front-entry
Gourmet Kitchen
Separate Living / Family Room
Slab
Suited for view lot
Vaulted Ceilings
Vaulted Living Room
