House Plan: DFD-5472

See All 5 Photos > (photographs may reflect modified homes)
© copyright by designer
SQ FT
4,251
BEDS
5
BATHS
4.5
STORIES
2
CARS
3
HOUSE PLANS SALE
START AT  $1,212.00
For questions and help, live chat, email or call us at 877-895-5299
Floor Plans
Click to Zoom In on Floor Plan

About House Plan 5472:
The elegant dining room's perimeter is defined by the large decorative pillars. With direct access to the bar/butlery, pantry and kitchen, serving is an ease. The kitchen has a free-standing island and breakfast bar offering plenty of counter space for any chef. Open to the kitchen are the breakfast area with its double door entry to the outdoor patio, and the family room with its warming fireplace.

This luxury Mediterranean house plan offers a private guest suite with a large walk-in closet, full bath, and den over the garage and an optional walkover for balcony access.

A quiet study with nook has access to one of the patios as well as the outdoor stoop. A family bedroom with full bath and walk-in closet completes this level of this house plan. Upstairs two family bedrooms share a full bath. One of the bedrooms has balcony access. A game and card room are the perfect gathering space for family and friends. The master suite boasts a large private balcony and lavish master bath with corner garden tub, separate shower, his and hers vanities and large wardrobe. The guest suite completes this level of this luxury Mediterranean house plan.
House Plan Pricing
STEP 1 Select Your Package

PDF Single Build


Digital plans emailed to you in PDF format that allows for printing copies and sharing electronically with contractors, subs, decorators, and more. This package includes a license to build the home one time.

PDF Single Build $1,365
Most recommended package

5 Printed Sets


Five Printed Sets of Residential Construction Drawings are typically 24” x 36” documents and come with a license to construct a single residence shipped to a physical address. Keep in mind PDF Plan Packages are our most popular choice which allows you to print as many copies as you need and to electronically send files to your builder, subcontractors, etc.

5 Printed Sets $1,545
Five printed sets of house plans

CAD Single Build


2D electronic computer files, completely editable, for design professional use, when making extensive modifications or in the event engineering is required in the area where you are building.

CAD Single Build $2,050
2D electronic editable computer files
STEP 2 Need To Reverse This Plan?
STEP 3 CHOOSE YOUR FOUNDATION
STEP 4 OPTIONAL ADD-ONS
Subtotal
$1365
FREE SHIPPING

Plan Details
See All Details
Finished Square Footage
1,965 Sq. Ft.
Main Level:
1,605 Sq. Ft.
Upper Level:
4,251 Sq. Ft.
Total:
Room Details
5
Bedrooms:
4
Full Baths:
1
Half Baths:
General House Information
2
Number of Stories:
45' 0"
Width:
103' 0"
Depth:
Single
Dwelling Number:
Unfinished Square Footage
861 Sq. Ft.
Garage:
681 Sq. Ft.
Bonus Room:
GARAGE
Side
Garage Location:
3
Garage Size:
Exterior Style
Mediterranean
Traditional
Collections
Luxury
Old House Classics
Foundation
Crawlspace
Slab
Framing Information
Stick
Roof Framing:
2x6
Exterior Wall Framing:
Roof Pitch
6
Primary:
Insulation (R)
0
Exterior Wall:
0
Interior Wall:
0
Ceiling:
0
Floor:
House And Ceiling Heights
10
First Floor Ceiling:
9
Second Floor Ceiling:
31' 0"
Maximum House Height:
Key Features
Detached
Dining Room
Family Room
Front Porch
Front-entry
Guest Suite
Kitchen Island
Primary Bdrm Upstairs
Nook / Breakfast Area
Rear Porch
Slab
Walk-in Closet
With Living Space
