House Plan: DFD-9486

See All 6 Photos > (photographs may reflect modified homes)
© copyright by designer
SQ FT
5,200
BEDS
6
BATHS
4.5
STORIES
2
CARS
2
HOUSE PLANS SALE
START AT  $2,080.00
For questions and help, live chat, email or call us at 877-895-5299
Floor Plans
Click to Zoom In on Floor Plan

About House Plan 9486:
If you have a large family that loves to be together but also enjoys private spaces to relax and unwind, this stunning three level 5,200 sq. ft. contemporary house plan should be at the top of your list.

Upon entering the main level of the home, you’ll feel the airiness of the 2 story foyer with a convenient powder room and coat closet to use and the guest ensuite bedroom is nearby. This main level is the gathering space with an open floor plan that is anchored by fireplace, an eat-at island, tons of natural light, and sliding glass doors leading to the deck.

Three bedrooms are located on the upper level including the master suite that has a walk-in closet, and a dual vanity bathroom with both a shower and a tub. The two secondary bedrooms share a hallway bath that is across from the laundry room of the home.

The lowest level has the remaining 2 bedrooms, and they share a compartmentalized hallway bathroom. There is an additional flex room that has a fireplace as well as an exterior exit onto a concrete patio.
House Plan Pricing
STEP 1 Select Your Package

PDF Single Build


Digital plans emailed to you in PDF format that allows for printing copies and sharing electronically with contractors, subs, decorators, and more. This package includes a license to build the home one time.

PDF Single Build $2,600
Most recommended package

5 Printed Sets


Five Printed Sets of Residential Construction Drawings are typically 24” x 36” documents and come with a license to construct a single residence shipped to a physical address. Keep in mind PDF Plan Packages are our most popular choice which allows you to print as many copies as you need and to electronically send files to your builder, subcontractors, etc.

5 Printed Sets $2,900
Five printed sets of house plans

8 Printed Sets


Eight Printed Sets of Construction Drawings, typically 24” x 36” documents, with a license to construct a single residence shipped to your physical address. PDF Plan Packages are our most popular choice which allows you to print as many copies as you need and to electronically send files to your builder, subcontractors, bank/mortgage reps, material stores, decorators and more.

8 Printed Sets $3,050
Eight printed sets of house plans

CAD Single Build


2D electronic computer files, completely editable, for design professional use, when making extensive modifications or in the event engineering is required in the area where you are building.

CAD Single Build $4,940
2D electronic editable computer files
STEP 2 Need To Reverse This Plan?
STEP 3 CHOOSE YOUR FOUNDATION
STEP 4 OPTIONAL ADD-ONS
Subtotal
$2600
FREE SHIPPING

Plan Details
See All Details
Finished Square Footage
2,031 Sq. Ft.
Main Level:
1,707 Sq. Ft.
Upper Level:
1,462 Sq. Ft.
Lower Level:
5,200 Sq. Ft.
Total:
Room Details
6
Bedrooms:
4
Full Baths:
1
Half Baths:
General House Information
2
Number of Stories:
59' 0"
Width:
70' 0"
Depth:
Single
Dwelling Number:
None
Bonus Access:
Unfinished Square Footage
587 Sq. Ft.
Garage:
109 Sq. Ft.
Porch:
104 Sq. Ft.
Deck:
GARAGE
Front
Garage Location:
2
Garage Size:
Exterior Style
Contemporary
Lake
Modern
Collections
Kitchens
Luxury
Primary Suites
Open Floor Plan
Outdoor Living
Foundation
Basement
Crawl Space
Crawlspace
Slab
Framing Information
Truss
Roof Framing:
2x6
Exterior Wall Framing:
Roof Pitch
4/12
Primary:
.25/12
Secondary:
Roof Load
25 psf
Live:
Insulation (R)
21
Exterior Wall:
House And Ceiling Heights
10
First Floor Ceiling:
9
Second Floor Ceiling:
37' 0"
Maximum House Height:
Key Features
2 Story Volume
Attached
Covered Front Porch
Deck
Dining Room
Double Vanity Sink
Exercise Room
Fireplace
Front-entry
Great Room
Guest Suite
Kitchen Island
Laundry 2nd Fl
Loft / Balcony
Primary Bdrm Upstairs
Open Floor Plan
Oversized
Peninsula / Eating Bar
Rear Porch
Rec Room
Storage Space
Suited for corner lot
Suited for narrow lot
Walk-in Closet
Walk-in Pantry
